The D24x40 set the industry standard in 1993, and today there are even more reasons it’s the trusted choice to meet contractors’ right-size, right-power needs.
With 28,000 lb (124.6 kN) of thrust and pullback and 4200 ft-lb (5694.4 Nm) of rotational torque — an increase over its predecessor (D24x40 Series II Navigator® horizontal directional drill) — the D24x40 S3 directional drill helps maximize machine and jobsite productivity, while class-leading cycle times help get the job done faster.
{"sku":"SKU|vermeer_126280","model":"Model|D24x40","feature_bullet_1":"Feature 1|The D24x40 S3 Navigator® horizontal directional drill carries on a proud legacy of reliability.","video_youtube":"YouTube URL|https://youtu.be/tcbP0mG4BpY","spec_ver_engine_option_two__50_aspiration":"Aspiration|Turbo","spec_ver_engine_option_two__310_make_and_model":"Make and Model|John Deere 4045","spec_ver_engine_option_two__280_gross_horsepower":"Gross Horsepower|125 hp","spec_ver_features__30_cab":"Cab|Optional","spec_ver_engine__200_fuel_type":"Fuel Type|Ultra low sulfur diesel","spec_ver_engine__50_aspiration":"Aspiration|Turbo","spec_ver_operational__300_thrust":"Thrust|28000 lbs","spec_ver_operational__250_pullback":"Pullback|28000 lbs","spec_ver_engine__280_make_and_model":"Make and Model|John Deere 4045","spec_ver_features__80_flow_indicator":"Flow Indicator|Standard","spec_ver_engine__240_gross_horsepower":"Gross Horsepower|125 hp","spec_ver_features__20_breakout_system":"Breakout System|Standard hydraulic vise","spec_ver_features__70_drilling_lights":"Drilling Lights|Standard","spec_ver_engine__320_maximum_engine_rpm":"Maximum Engine RPM|2400 rpm","spec_ver_features__240_stakedown_system":"Stakedown System|Standard","spec_ver_fluid_capacities__10_fuel_tank":"Fuel Tank|44 gal","spec_ver_drill_rack__10_drill_rack_angle":"Drill Rack Angle|4200 ft-lb","spec_ver_engine__300_max_fuel_consumption":"Max Fuel Consumption|6.8 gph","spec_ver_fluid_capacities__30_hydraulic_tank":"Hydraulic Tank|55 gal","spec_ver_operational__10_automated_rod_loader":"Automated Rod Loader|Yes","spec_ver_fluid_capacities__20_hydraulic_system":"Hydraulic System|65 gal","spec_ver_operational__170_minimum_bore_diameter":"Minimum Bore Diameter|4 in","spec_ver_general_dimensions_and_weights__740_weight":"Weight|21750 lbs","spec_ver_operational__200_noise_level_at_operators_ear":"Noise Level at Operator's Ear|83 dB(A)","spec_ver_general_dimensions_and_weights__220_height_with_cab":"Height (With Cab)|102 in","spec_ver_hydraulic_system__150_auxiliary_pump_relief_pressure":"Auxiliary Pump Relief Pressure|3000 psi","spec_ver_hydraulic_system__270_hydraulic_return_filter_rating":"Hydraulic Return Filter Rating|Dual 5 micron filters","spec_ver_hydraulic_system__280_hydraulic_supply_filter_rating":"Hydraulic Supply Filter Rating|9 micron","spec_ver_operational__100_maximum_spindle_speed_at_max_engine_rpm":"Maximum Spindle Speed at Max Engine RPM|270 rpm","spec_ver_general_dimensions_and_weights__390_length_minimum_transport":"Length (Minimum Transport)|241 in","spec_ver_operational__70_maximum_carriage_speed_at_maximum_engine_rpm":"Maximum Carriage Speed at Maximum Engine RPM|240 ft/min","spec_ver_hydraulic_system__130_auxiliary_pump_flow_at_maximum_engine_rpm":"Auxiliary Pump Flow at Maximum Engine RPM|9 gpm","spec_ver_operational__90_maximum_ground_drive_speed_at_maximum_engine_rpm":"Maximum Ground Drive Speed at Maximum Engine RPM|3.3 mph","spec_ver_operational__140_maximum_spindle_torque_high_at_maximum_engine_rpm":"Maximum Spindle Torque (High at Maximum Engine RPM)|2000 ft-lb","spec_ver_operational__160_maximum_spindle_torque_medium_at_maximum_engine_rpm":"Maximum Spindle Torque (Medium at Maximum Engine RPM)|3500 ft-lb","spec_ver_general_dimensions_and_weights__1160_width_with_cab_minimum_transport":"Width (With Cab, Minimum Transport)|89 in","spec_ver_engine_option_two__270_fuel_type":"Fuel Type|Diesel","spec_ver_engine_option_two__180_emissions_rating":"Emissions rating|Tier 3/Stage IIIA","spec_ver_engine_option_two__400_maximum_operating_angle_left_right":"Maximum Operating Angle (Left/Right)*|30 deg","spec_ver_engine_option_two__330_max_fuel_consumption":"Max Fuel Consumption|6.8 gph","spec_ver_features__250_strike_alert":"Strike Alert|Standard","spec_ver_engine__150_emissions_rating":"Emissions rating|Tier 4 Final (EU Stage V)","spec_ver_features__180_remote_lockout":"Remote Lockout|Standard","spec_ver_engine_option_two__360_maximum_engine_rpm":"Maximum Engine RPM|2400 rpm","spec_ver_operational__40_guaranteed_sound_power_ce_rating":"Guaranteed sound power (CE-rating)|105 dB(A)","spec_ver_drilling_fluid_system_option_one__20_maximum_flow":"Maximum Flow|50 gpm","spec_ver_general_dimensions_and_weights__10_angle_of_approach":"Angle of Approach|19 deg","spec_ver_drilling_fluid_system_option_one__30_maximum_pressure":"Maximum Pressure|1050 psi","spec_ver_general_dimensions_and_weights__1130_width_minimum_transport":"Width (Minimum Transport)|89 in","spec_ver_general_dimensions_and_weights__210_height_minimum_transport":"Height (Minimum Transport)|76 in","spec_ver_operational__80_maximum_carriage_speed_in_low_at_maximum_engine_rpm":"Maximum Carriage Speed in Low at Maximum Engine RPM|101 ft/min","spec_ver_drilling_fluid_system_option_one__10_brand":"Brand|Aplex","spec_ver_engine__340_maximum_operating_angle_fore_aft":"Maximum Operating Angle (Fore/Aft)*|30","spec_ver_engine__330_maximum_operating_angle_left_right":"Maximum Operating Angle (Left/Right)*|25/25","spec_ver_general_dimensions_and_weights__870_weight_cab_option":"Weight (Cab Option)|22250 lbs","spec_ver_drilling_fluid_system_option_one__40_on_board_tank_capacity":"On Board Tank Capacity|6 gal"}
