The compact-sized wheeled paver in the 8-foot-class. The wheeled SUPER 1703-3i paver has been specially designed for the requirements of the North American and Australian market. The 8-foot class wheeled paver is an all-rounder with great mobility. With its compact dimensions and Pivot Steer brake, the wheeled paver features excellent maneuverability, making it suitable for a wide variety of applications. The VÖGELE ErgoPlus 3 operating concept makes using the paver even safer and easier.
{"sku":"SKU|SUPER_1703-3i","model":"Model|SUPER 1703-3i","product_brochure_url":"Product Brochure PDF URL|https://www.wirtgen-group.com/binary/full/o7210v89_PB_SUPER17033i_2566451US_0517_Web.pdf","spec_notab_clustered_specs":"Specifications|
Engine Manufacturer: Cummins
Engine Type: QSB 4.5 - C173
Engine Nominal output: 173 hp / 2000 RPM
Engine ECO mode output: 160 hp / 1700 rpm
Engine Exhaust emissions standard: European exhaust emissions standard 4, US standard EPA Tier 4f
Engine Exhaust emissions after-treatment: DOC, SCR
Front wheels Tire equipment: Elastic solid rubber tires
Front wheels Tire size, front wheels: 540/300–390
Rear wheels Version: 2, pneumatic, tubeless
Rear wheels Tire size, rear wheels: 14.00 R25
Traction drive Version: Separate hydraulic drives
Traction drive Standard: 2 rear and 2 front wheels (6x4)
Traction drive Option: 2 rear and 4 front wheels (6x6)
Steering: hydraulic
Brakes Service brake: generously-dimensioned multiple-disk brakes operated by foot pedal, maintenance-free
Brakes Parking brake: spring-loaded multiple-disk brake, maintenance-free
Brakes Auxiliary brake: hydrostatic brake
Speeds Travel speed (up to): 12.5 mph
Speeds Paving speed (up to): 250 fpm
Push-rollers Positions: can be adjusted in a forward direction by 3 or 6 in
Conveyors Version: with replaceable feeder bars, direction of conveyor temporarily reversible
Conveyors Drive: separate hydraulic drives, proportional control
Augers: 2
Augers Version: with replaceable auger blades, reversible direction of rotation
Augers Speed: 120 rpm
Augers Drive: separate hydraulic drives, proportional control
Augers Height: infinitely variable
Augers Standard height: hydraulically adjustable by 6 in
Lubrication: centralized lubrication system, electrically-driven grease pump
Power supply: three-phase AC generator
Screed:
Length:
Maximum laydown rate: 770 US t/hr"}
Drive
Engine Version: liquid-cooled 4-cylinder diesel engineEngine Manufacturer: Cummins
Engine Type: QSB 4.5 - C173
Engine Nominal output: 173 hp / 2000 RPM
Engine ECO mode output: 160 hp / 1700 rpm
Engine Exhaust emissions standard: European exhaust emissions standard 4, US standard EPA Tier 4f
Engine Exhaust emissions after-treatment: DOC, SCR
Undercarriage
Front wheels Version: 4, mounted on bogiesFront wheels Tire equipment: Elastic solid rubber tires
Front wheels Tire size, front wheels: 540/300–390
Rear wheels Version: 2, pneumatic, tubeless
Rear wheels Tire size, rear wheels: 14.00 R25
Traction drive Version: Separate hydraulic drives
Traction drive Standard: 2 rear and 2 front wheels (6x4)
Traction drive Option: 2 rear and 4 front wheels (6x6)
Steering: hydraulic
Brakes Service brake: generously-dimensioned multiple-disk brakes operated by foot pedal, maintenance-free
Brakes Parking brake: spring-loaded multiple-disk brake, maintenance-free
Brakes Auxiliary brake: hydrostatic brake
Speeds Travel speed (up to): 12.5 mph
Speeds Paving speed (up to): 250 fpm
Material hopper
Push-rollers Standard: oscillatingPush-rollers Positions: can be adjusted in a forward direction by 3 or 6 in
Conveyors and augers
Conveyors: 2Conveyors Version: with replaceable feeder bars, direction of conveyor temporarily reversible
Conveyors Drive: separate hydraulic drives, proportional control
Augers: 2
Augers Version: with replaceable auger blades, reversible direction of rotation
Augers Speed: 120 rpm
Augers Drive: separate hydraulic drives, proportional control
Augers Height: infinitely variable
Augers Standard height: hydraulically adjustable by 6 in
Lubrication: centralized lubrication system, electrically-driven grease pump
Screed
Screed heating: electric, thermostat-controlledPower supply: three-phase AC generator
Screed:
| Type | Basic width | Maximum width | Compacting systems |
| VF 500 | 8 ft | 19 ft 6 in | V |
Dimensions and weights
Operating weight:| Screed | Total weight |
| VF 500 | 38,030 lbs |
| Screed | Total length |
| VF 500 | 19 ft 7 in |
